Triple concertina Razor Wire is a robust security solution designed to provide enhanced protection through its layered spiral configuration. Here are the detailed specifications for triple concertina razor wire: Specifications
General Characteristics
- Material: Available in galvanized steel or stainless steel, ensuring high durability and corrosion resistance.
- Core Wire Diameter: Typically 2.5 mm, which offers significant tensile strength.
- Blade Thickness: Commonly 0.5 mm.
- Blade Types: Includes various blade styles such as BTO-10, BTO-22, CBT-60, and CBT-65.
Coil Details
- Diameter Options: Common diameters include 450 mm, 600 mm, 750 mm, and 900 mm.
- Length per Coil: Standard lengths are typically around 10 m or more, depending on the specific product.
- Loops per Coil: Generally contains 54 to 55 loops, allowing for effective deployment and security density.
Blade Specifications
Blade Type | Barb Length (mm) | Barb Width (mm) | Barb Spacing (mm) | Core Wire Diameter (mm) |
BTO-10 | 10 | 13 | 25 | 2.5 |
BTO-22 | 22 | 16 | 35 | 2.5 |
CBT-60 | 60 | 31 | 100 | 2.5 |
CBT-65 | 65 | 21 | 100 | 2.5 |
Performance Features
- Clips per Loop: Typically features either three or five clips per loop, enhancing the security profile when deployed.
- Extended Length: When fully deployed, triple concertina razor wire can cover considerable lengths, often between 4.5 m to over 10 m depending on the coil size and configuration.
Applications
Triple concertina razor wire is ideal for various high-security environments:
- Military Installations: Provides a formidable barrier against unauthorized access.
- Prisons: Deters escape attempts effectively.
- Industrial Sites: Protects sensitive areas against intruders.
- Perimeter Security: Suitable for securing borders and critical infrastructure.
Advantages
- Enhanced Security: The triple-layered design significantly increases the difficulty of climbing or breaching the barrier.
- Versatile Installation: Can be installed on various structures and combined with other Fencing types for improved security.
- Cost-Effective Solution: Offers high security at a relatively low cost compared to alternative fencing options.
In summary, triple concertina razor wire provides a high level of security through its robust design and specifications, making it suitable for a range of applications where enhanced protection is essential.
